Name: Factory Price Open/Silent Type SDEC Diesel Generator 80KW/100KVA Backup Power Supply Water Cooling
Brand: FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
SKU: SC4H140D2
Price: 1,600.00 USD
Availability: InStock

বৈশিষ্ট্য গ্যালারী পণ্যের বর্ণনা উদ্ধৃতির জন্য আবেদন

বৈশিষ্ট্য

বিশেষ উল্লেখ

গতি: 1500rpm

ফ্রিকোয়েন্সি: 50/60Hz

রেট পাওয়ার: 5KW থেকে 2000KW

আউটপুট প্রকার: এসি থ্রি ফেজ

টাইপ: খোলা বা নীরব (সুপার সাইলেন্ট)

রঙ: আপনার প্রয়োজনে, কাস্টমাইজড

বিশেষভাবে তুলে ধরা:

80KW SDEC diesel generator

silent type diesel generator

water cooling backup power supply

মৌলিক তথ্য

উৎপত্তি স্থল: চীন

পরিচিতিমুলক নাম: SDEC

মডেল নম্বার: SC4H140D2

প্রদান

প্যাকেজিং বিবরণ: পাতলা পাতলা কাঠ

ডেলিভারি সময়: 10 কাজের দিন

পরিশোধের শর্ত: এল/সি, টি/টি

যোগানের ক্ষমতা: প্রতি মাসে 50 সেট

গ্যালারী

Factory Price Open/Silent Type SDEC Diesel Generator 80KW/100KVA Backup Power Supply Water Cooling

পণ্যের বর্ণনা

Factory Price Open/Silent Type SDEC Diesel Generator 80KW/100KVA Backup Power Supply Water Cooling

Product Features

Equipped with famous Brushless alternator - Leroy Somer, Marathon, BOBIG, Mecc alte
Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working
Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system
Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
Equipped with high density sound-absorbing material -- sound insulation, fireproofing
Generator equipped with 12V/24V DC battery with charger, battery connects wire
Generator equipped with 10-12 hours fuel tank with fuel indicator, long time for working
High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker
New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency
Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance
Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator
All new design for diesel generator set of Silent, Supper silent, Soundproof, Trailer type, Container type
Our generator set compliance with all main standards: GB/T2820, ISO8528, IEC34, CE, EPA Tier4 standard

Technical Specifications

General Information	Prime Power	Standby Power
Rated Power (kVA)	100	110
Power Rating (kW)	80	88
Frequency (Hz)	50
Engine Model	SC4H140D2
Engine Speed (RPM)	1500
Phase	3
PF	0.8
Control System	Digital
Rated voltage (V)	400/230
Fuel tank capacity operating time	≥ 8h @ 75% load

PRP: Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation.
ESP: The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.

Dimensions and Weight

Model	BSD110 (Open type)	BSD110S (Silent type)
Length (mm)	2000	2750
Width (mm)	850	1100
Height (mm)	1580	1430
Tank capacity (L)	184	184

Note: Specifications and illustrations are subject to revision without notice.

Engine Specifications

Engine Model & Manufacturer	SC4H140D2 (SDEC)
Engine Type	In-line, 4 strokes, water-cooled; 4 valves, Turbo charged
Combustion type	Direct injection
Cylinder Type	Dry cylinder liner
Number of cylinders	4
Bore × stroke	105 × 124 mm
Displacement	4.3 lit.
Compression ratio	16 : 1
Firing order	1-3-4-2
Fuel injection advance angle	11°BTDC
Dry weight	460 kg
Dimension	1080x738x1078mm
Rotation	CCW viewed from flywheel

Alternator Specifications

Alternator Brand	BOBIG
Alternator Manufacturer	FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model	BW-274C
Alternator Rated Power	80kw/100kva
Rated voltage (V)	230v/400v
Rated frequency	50hz
Connecting Type	3 Phase and 4 W
Number of Bearing	1
Protection Grade	IP23
Altitude	≤1000m
Exciter Type	Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class	H class
